ET-2261

Providing various digital I/O functions, the ET-2261 module is an IP-based Ethernet I/O monitoring and control module. The module can be remotely controlled through a 10/100 M Ethernet network by using Modbus TCP/UDP protocol. Modbus has become a de facto standard communications protocol in industry, and is now the most commonly available means of connecting industrial electronic devices. This makes the ET-2261 module perfect integration with the HMI, SCADA, PLC and other software systems.

  • Built-in Web Server
  • Support Modbus TCP/UDP Protocols
  • Powerful 32-bit MCU Handles Efficient Network Traffic
  • 2-port Ethernet Switch (LAN Bypass) for Daisy-Chain Wiring
  • Dual Watchdog
  • I/O Pair Connection (Push and Polling)
  • Supports web configuration and firmware update via Ethernet
  • Built-in I/O Power Relay Output Channels
    • 10-channel
  • LED Display to Indicate the I/O status
  • Wide Operating Temperature Range: -25 ~ +75°C

ET-2261 CR: Ethernet I/O Module with 2-port Ethernet Switch, 10-ch Power Relay Output (RoHS)

  • ICP DAS
