VBOX-3630

VBOX-3630 Intel® 11th Gen Core™ i7-1185G7E CPU with 4x Gbe LAN On-Board Computer

It features:

  • Intel® 11th Gen Core™ i7-1185G7E
  • Supports Dual 5G / LTE, GPS, Wi-Fi / BT, and CAN Bus Modules
  • Wide Range DC Input 9V – 60VDC with In-Vehicle Power Management for EV Installations
  • 1 x 2.5GbE + 3 x GbE LAN Port (M12 and PoE are optional)
  • Supports 4 Independent Display Outputs: 2 x HDMI, 1 x DP, 1 x DVI-D
  • Supports Optional Backup Battery Kit
  • E13 and EN50155 Certified

ICP Electronics Australia is pleased to present Sintrones VBOX-3630. A fanless in-car computer with 5G connectivity is the VBOX-3630. It uses a 4.4GHz Intel® CoreTM i7-1185G7E CPU from the 11th generation.

The ultra-compact VBOX-3630, with dimensions of 250 x 165 x 55mm, is perfect for confined locations. The system can use M.2 modules for robust communication via 5G, LTE, GPS, Wi-Fi, and Bluetooth. It has a microphone in, an audio line out, and four independent display outputs. It is ideal for mobile DVR, in-vehicle digital signage, and fleet management.

It also includes a wireless remote control and Smarter Vehicle Power Ignition in a variety of automobiles, trucks, buses, taxis, and forklifts may all be supported by VBOX-3630 in a variety of harsh working environments and weather situations.

Part Number: VBOX-3630x-yyyy-zz(x=P=w/PoE, yyyy=M12X-code for LAN ports, zz=i7-1185G7E, zz=i5-1145G7E, zz=i3=1115G4E, zz=C1=6305E)

Description: Intel 11th Gen Core i7-1185G7E CPU with 4 x GbE LAN On-Board Computer

State of Origin: Made in Taiwan

  • SINTRONES
