tDS-718-T

tDS-718-T is a Serial-to-Ethernet device server that is designed to add Ethernet and Internet connectivity to any RS-232 and RS-422/485 device and to eliminate the cable length limitation of legacy serial communication.

KEY FEATURES:

  • Incorporates any RS-232/422/485 Serial Device in Ethernet
  • Data Transmission via Virtual COM or Raw TCP Connection
  • VxComm Driver for 32- and 64-bit Windows 7 SP1/10/2012/2016
  • Connections : 1 Socket per Serial Port is Suggested
  • Supports Pair-Connection (Serial-Bridge, Serial-Tunnel) Applications
  • Supports TCP Client-Mode and TCP Server-Mode Operations
  • Supports UDP Responder for Device Discovery (UDP Search)
  • Static IP or DHCP Network Configuration
  • Easy Firmware Update via the Ethernet (BOOTP, TFTP)
  • Tiny Web Server for Configuration (HTTP)
  • Contains a 32-bit MCU that Efficiently Handles Network Traffic
  • 10/100 Base-TX Ethernet, RJ-45 x 1 (Auto-Negotiating, Auto MDI/MDIX, LED Indicators)
  • Power Input: DC Terminal Block
  • Allows Automatic RS-485 Direction Control
  • 3000 VDC Isolation and +/-4 kV ESD Protection for I Versions
  • Terminal Block Connector for Easy Wiring
  • Tiny Form-Factor and Low Power Consumption
  • RoHS Compliant & No Halogen
  • Cost-Effective Device Servers
tDS-718-T     CR  Tiny (1x RS-232/422/485) Serial-to-Ethernet Device Server (RoHS)
