PUZZLE-IN003B

Puzzle-IN003B is a Desktop Network Device that can be easily places in space limited areas. It comes with Intel® Atom® Processor C3000 series System On Chip (4 core to 16 core and up to 2.2Ghz ) which supports up to 128GB Dual-channels DDR4 2400 MHz ECC (UDIMM, or RDIMM), 32GB Embedded Multi Media Card (eMMC), and have High Speed Network Data Transmission of 2 x 10Gb integrated Ethernet and 6 x 1Gb RJ-45 LAN ports.

  • Intel® Atom® Processor C3000, Processor up to 16 CPU Cores
  • Support Six GbE and Two 10 GbE SFP+ via Integrated C3558/C3758
  • DDR4 2133MHz ECC or non-ECC UDIMM / RDIMM up to 128GB
  • 1 x 2230 M.2 A Key (USB 2.0, PCIe x1), 1 x 2260/2280 M.2 M Key, 1 x PCIe Mini (USB 2.0, PCIe x1), SIM Card Slot, 1 x eMMC 32GB

PUZZLE-IN003B-C0/8G-R10: Desktop Network Appliance with Intel® ATOM® C3758 Processor , 6 x 1GbE, 2 x 10 GbE,8GB DDR4, eMMC 32GB & 2x M.2 slot
PUZZLE-IN003B-C1/8G-R10: Desktop Network Appliance with Intel® ATOM® C3558 Processor , 6 x 1GbE, 2 x 10 GbE, 8GB DDR4, eMMC 32GB & 2x M.2 slot

  • IEI Integration
