NANO-ADL-P

EPIC SBC supports Intel® Alder Lake-P Core™ i7/i5/i3 and Celeron® processor with 8GB LPDDR4x memory on board default, with Dual HDMI, DP, IDPM, M.2 A key, M.2 B key, USB 3.2, SATA 6Gb/s, COM, IAUDIO, PCIe x4 for riser card and RoHS



KEY FEATURES:

  • Support 12th Intel® mobile AlderLake-P on board SoC
  • Support on-board LPDDR4x 3200 MHz 8GB memory, up to 16GB
  • Support quadruple independent display via two HDMI, one DP and one iDPM
  • Support PCIE X4,M.2 B key and M.2 A key expansion
  • Suport two 2.5GbE LAN with i225-V

ICP Electronics Australia is proud to introduce iEi’s NANO-ADL-P. The NANO-ADL-P, a high-performance EPIC SBC from iEi, offers robust functionality with the integration of the 13th Gen Intel® Core™ i7/i5/i3 and Celeron® processors, coupled with a standard 8GB LPDDR4x on-board memory that can be expanded up to 16GB. This powerhouse SBC employs a 12th Intel® mobile AlderLake-P on-board SoC, paving the way for superior multi-tasking capabilities.

The device uniquely supports quadruple independent displays via two HDMI ports, one DP, and an innovative iDPM interface designed by iEi. The iDPM interface can be tailored to user requirements, enabling the addition of LVDS/eDP/VGA display interfaces.

Expanding on its high-end performance, the NANO-ADL-P supports PCIe X4, M.2 B key, and M.2 A key expansions. In addition, it supports two 2.5GbE LAN interfaces with the Intel® I225V network controller, delivering a network transmission rate of up to 2.5GbE.

In sum, the NANO-ADL-P exemplifies iEi’s commitment to delivering versatile, powerful, and user-friendly computing solutions. Its standout features and high-performance capabilities make it an excellent choice for various applications.

Ordering Information

NANO-ADL-P-i7C-R10 EPIC SBC supports Intel® Alder Lake-P Core™ i7-1255U processor with 8GB LPDDR4x memory on board default, with Dual HDMI,DP,IDPM,M.2 A key, M.2 B key, USB 3.2, SATA 6Gb/s, COM, IAUDIO,PCIe x4 for riser card and RoHS
NANO-ADL-P-i5C-R10 EPIC SBC supports Intel® Alder Lake-P Core™ i5-1235U processor with 8GB LPDDR4x memory on board default, with Dual HDMI,DP,IDPM,M.2 A key, M.2 B key, USB 3.2, SATA 6Gb/s, COM, IAUDIO,PCIe x4 for riser card and RoHS
NANO-ADL-P-i3C-R10 EPIC SBC supports Intel® Alder Lake-P Core™ i3-1215U processor with 8GB LPDDR4x memory on board default, with Dual HDMI,DP,IDPM,M.2 A key, M.2 B key, USB 3.2, SATA 6Gb/s, COM, IAUDIO,PCIe x4 for riser card and RoHS
NANO-ADL-P-CC-R10 EPIC SBC supports Intel® Alder Lake-P Celeron® 7305 processor with 8GB LPDDR4x memory on board default, with Dual HDMI,DP,IDPM,M.2 A key, M.2 B key, USB 3.2, SATA 6Gb/s, COM, IAUDIO,PCIe x4 for riser card and RoHS
