SKU 3269

The MI956F Mini-ITX motherboard is based on the latest Intel® QM67 Express chipset. The platform supports the 2nd generation Intel® Core processor family with rPGA988B packing and features an integrated dual-channel DDR3 memory controller as well as a graphics core. It meets the requirement in the gaming, POS, digital signage and server market segment.

Measuring 170mm x 170mm, the MI956F offers fast 6Gbps SATA support (2 ports), USB 3.0 (2 ports) functionality and interfaces for DVI-D, DVI-I, LVDS and HDMI displays. Another board model, MI956AF, features Intel Active Management Technology 7.0.

  • Supports 2nd/3rd Generation Intel® Core™ i7/i5/i3 /     Celeron® QC/DC processors, up to 2.7GHz
  • 2x DDR3 SO-DIMM, Max. 16GB
  • Integrated VGA, Supports DVI-I/DVI-D/LVDS/HDMI
  • Dual Gigabit LAN
  • 8x USB 2.0, 2x USB 3.0, 4x COM, 4x SATA II, 2x SATA III
  • 1x PCI-E(x16), 1x Mini PCI-E(x1)
  • Watchdog timer, Digital I/O

MI956F:  rPGA988B QM67 Mini-ITX motherboard w/ DVI-I, DVI-D, HDMI, dual Gigabit LAN, EuP/ErP compliant

MI956AF:  rPGA988B QM67 Mini-ITX motherboard w/ DVI-I, DVI-D, HDMI, dual Gigabit LAN, iAMT (7.0), RAID
